Lifting capacity:
1500 kg
|
|
Lifting height max.:
3500 mm
|
|
Battery type:
Lead acid gel
|
|
Battery voltage:
12V / 75 aH
|
|
Power supply:
230V
|
|
Drive motor power:
0.75 kW
|
|
Lift motor power:
2.2 kW
|
|
Lifting speed loaded:
0 - 85 mm/sec
|
|
Lifting speed unloaded:
0-130 mm/sec
|
|
Lowering speed loaded:
27-137 mm/sec
|
|
Lowering speed unloaded:
22-167 mm/sec
|
|
Driving speed loaded max.:
4 km/h
|
|
Driving speed no-load max.:
4.5 km/h
|
|
Turning radius:
1490 mm
|
|
Gradeability max. loaded / unloaded:
5% / 10%
|
|
Fork size (length x width x height):
1150 x 160 x 65mm
|
|
Fork overall width:
560 mm
|
|
Wheel material:
Polyurethane
|
|
Brake type:
Electromagnetic
|
