Lifting capacity:
500 kg
|
|
Lifting height max.:
1020 mm
|
|
Battery type:
Lead acid gel
|
|
Battery voltage:
12V / 45 aH
|
|
Power supply:
230V
|
|
Lift motor power:
0.8 kW
|
|
Lifting speed loaded:
45 mm/sec
|
|
Lifting speed unloaded:
55 mm/sec
|
|
Lowering speed loaded:
80 mm/sec
|
|
Turning radius:
1100 mm
|
|
Gradeability max. loaded / unloaded:
5% / 10%
|
|
Fork size (length x width x height):
1150 x 190 x 60 mm
|
|
Fork overall width:
560 mm
|
|
Wheel material:
Nylon
|
|
Mast lowered height:
1325 mm
|
|
Mast extend height:
2305 mm
|
